- Sensor:
- Pixel: 5 MP
- Sensor Size: 1/2.7″ CMOS
- Min. Illumination: 0.02 lux (F2.0, AGC ON), 0 lux (IR on)
- Lens:
- Focus: 2.8 mm
- Lens Mount: M12
- Angle of View (H): 102.2°
- Angle of View (V): 53.9°
- Angle of View (D): 124.8°
- Illuminator:
- Illuminator Number: One IR illuminator
- Illumination Distance: 20m
- Lifetime: ≥ 60000 hours
- Video:
- Resolution:
- 5MP@25fps: 2880(H)×1620(V)
- 5MP@20fps: 2592(H)×1944(V)
- 5MP@12.5fps: 2592(H)×1944(V)
- 4MP: 2560(H)×1440(V)
- 1080P: 1920(H)×1080(V)
- Frame Rate:
- TVI: 5MP@20fps (default), 5MP@12.5fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- AHD: 5MP@20fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVI: 5MP@25fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVBS: PAL, NTSC
- Shutter Time: PAL: 1/25s-1/50000s, NTSC: 1/30s-1/50000s
- Resolution:
- Image:
- Exposure Mode: Four modes (Global, BLC, HLC, DWDR)
- Day/Night: Three modes (Auto, Day, Night)
- Digital Noise Reduction: 2D
- White Balance: Auto (default), Manual
- WDR: DWDR
- Smart IR: Support
- Flip: Supports 180° horizontal flip, 180° vertical flip
- Interface:
- Power Interface: 5.5 mm Power Interface
- Video Output: BNC, supports TVI/AHD/CVI/CVBS
- Operating Environment:
- Temperature: -30°C to 60°C (-22°F to 140°F)
- Humidity: ≤ 95% RH (non-condensing)
- Surge Protection: 4 KV for power, 4 KV for video output interfaces
- General:
- Power: DC 12 V ± 25%
- Power Consumption: MAX 3.6W
- Mount: Corner Mount, Pole Mount
- Dimensions: 142mm × 63mm × 65mm (L×W×H)
- Material: Plastic
- Weight: 135g (0.30lb)
- Certification:
- EMC: CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035), FCC (FCC 47 CFR part15 B)
- Safety: CE-LVD (EN 62368-1)
- Environment: CE-RoHS (2011/65/EU; (EU) 2015/863), WEEE (2012/19/EU)
- Protection: IP67 (IEC 60529)
Camera UNIVIEW Analogue 5MP 2.8mm Out Bullet UAC-B115-F28
5MP Fixed IR Bullet Analog Camera
• 5MP high quality image
• TVI/AHD/CVI/CVBS
• IR-cut filter with auto switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• TVI/AHD/CVI/CVBS
• IR-cut filter with auto switch (ICR)
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
