-Pure sine wave inverter
-Built-in MPPT solar charge controller (Supports 2 strings of solar input)
-Built-in Wi-Fi for mobile monitoring (APP is required)
-Configurable input voltage range for home appliances and personal computers via LCD setting
-Configurable battery charging current based on applications via LCD setting
-Configurable AC / Solar Charger priority via LCD setting
-Compatible to mains voltage or generator power
-The generator input port can be changed to a smart output port
-Control smart output port can customize output duration
-Auto restart while AC is recovering
-Overoad/ Over temperature/ short circuit protection
-Inverter running without battery
-Lithium battery activation function
-Cold start function
-Parallel connection quantity up to 6units (Battery must be connected).
SPECIFICATIONS
Electrical Specifications:
- Rated Output Power: 8000VA / 8000W
- Nominal DC Input Voltage: 48V
- Input Voltage Waveform: Sinusoidal (utility or generator)
- Nominal Input Voltage: 230Vac
- Low Line Voltage Disconnect:
- 170Vac ±7V (UPS)
- 90Vac ±7V (Appliances)
- Low Loss Voltage Re-connect:
- 180Vac ±7V (UPS)
- 100Vac ±7V (Appliances)
- High Line Voltage Disconnect: 280Vac ±7V
- High Line Voltage Re-connect: 270Vac ±7V
- Max AC Input Voltage: 280Vac
- Nominal Input Frequency: 50Hz / 60Hz (Auto detection)
- Low Line Frequency Disconnect: 40 ±1Hz
- Low Line Frequency Re-connect: 42 ±1Hz
- High Line Frequency Disconnect: 65 ±1Hz
- High Line Frequency Re-connect: 63 ±1Hz
- Output Voltage Waveform: Same as input waveform
- Output Short Circuit Protection:
- Line mode: Circuit Breaker
- Battery mode: Electronic Circuits
- Efficiency (Line Mode): >95% (Rated R load, battery fully charged)
- Transfer Time (Single Unit):
- 10ms typical (UPS)
- 20ms typical (Appliances)
- Transfer Time (Parallel): 50ms typical
- Pass Through Without Battery: Yes
- Max Bypass Overload Current: 53A
- Max Inverter / Rectifier Current: 40A / 8000W
Utility Charge Mode Specifications:
- Nominal Input Voltage: 230Vac
- Input Voltage Range: 90 ~ 280Vac
- Nominal Output Voltage: Dependent on battery type
- Max Charge Current: 150A
- Charge Current Regulation: 10-150A (Adjustable unit is 1A)
- Over Charge Protection: Yes
Solar Charging & Grid Charging Specifications:
- Max PV Open Circuit Voltage: 500V
- PV Voltage Working Range: 90V – 450V
- Max Input Power: 10000W (5000W for single PV)
- Max Solar Charging Current: 150A
- Max Charging Current (PV + Grid or GEN): 150A
- Max Input Current: 20Ax2 (Max 40A)
- Min Startup Voltage: 100V
