- Sensor:
- Pixel: 5 MP
- Sensor Size: 1/2.7″ CMOS
- Minimum Illumination: 0.005 lux (F1.6, AGC ON), 0 lux (IR on)
- Lens:
- Focus: 2.8 mm
- Lens Mount: M12
- Angle of View (H): 109.1°
- Angle of View (V): 60.9°
- Angle of View (D): 126.7°
- Illuminator:
- Illuminator Number: Two IR illuminators
- Illumination Distance: 40m
- Lifetime: ≥ 60,000 hours
- Video:
- Resolution:
- 5MP@25fps: 2880(H) × 1620(V)
- 5MP@20fps: 2592(H) × 1944(V)
- 5MP@12.5fps: 2592(H) × 1944(V)
- 4MP: 2560(H) × 1440(V)
- 1080P: 1920(H) × 1080(V)
- Frame Rate:
- TVI: 5MP@20fps (default), 5MP@12.5fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- AHD: 5MP@20fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVI: 5MP@25fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVBS: PAL, NTSC
- Shutter Time: PAL: 1/25s–1/50000s, NTSC: 1/30s–1/50000s
- Resolution:
- Image:
- Exposure Mode: Four modes (Global, BLC, HLC, DWDR)
- Day/Night: Three modes (Auto, Day, Night)
- Digital Noise Reduction: 2D
- White Balance: Auto (default), Manual
- WDR: DWDR
- Smart IR: Support
- Flip: Supports 180° horizontal flip, 180° vertical flip
- Digital Defog: Not Available
- Audio:
- Built-in Mic: Support
- Camera Audio:
- TVI: 5MP@20fps, 5MP@12.5fps, 4MP@25fps, 4MP@30fps, 1080P@25fps, 1080P@30fps
- CVI: 5MP@25fps, 4MP@25fps, 4MP@30fps
- Interface:
- Power Interface: 5.5mm power interface
- Video Output: BNC, supports TVI/AHD/CVI/CVBS
- Operating Environment:
- Temperature: -30°C to 60°C (-22°F to 140°F)
- Humidity: ≤ 95% RH (non-condensing)
- Surge Protection: 4 kV for power, 4 kV for video output interfaces
- Ingress Protection: IP67
- General:
- Power: DC 12V ± 25%
- Power Consumption: Max 3.4W
- Mount: Corner Mount, Pole Mount
- Dimensions: 154mm × 66mm × 66mm (L × W × H)
- Material: Graphene + Metal + Plastic
- Weight: 240g (0.53lb)
Camera 5MP Out Mic UAC-B125-AF28LM
5MP LightHunter Fixed IR Bullet Analog Camera
• High quality imaging with 5MP resolution
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
• TVI/AHD/CVI/CVBS
• Supports IR-cut filter with auto-switch (ICR)
• LightHunter monitoring with high-sensitivity sensor
• Supports 180° horizontal flip, 180° vertical flip
• OSD configuration menu, easy to operate
• IP67 waterproof and dustproof design, high reliability
• OSD configuration menu in 11 languages
• Built-in microphone for high quality audio transmission via coaxial cables
